Solid State Pulsed Power Modulator

High Voltage Electrotechnix

Major Developed Products

Total 5건 1 페이지

HVP-1050
- Solid state modulator for PSII, DLC coating
- Pulse Output: 10kV/50A,(5MW)
- PW: 200ns~10us
- PRR: ~200kHz
- Average Power: 8kW
- Input: 3*380Vac
- Compact, High repetitive
HVP-40150/40300
- Solid state modulator for Gas Treatment, PEF(Pulsed Electric Field)
- Pulse Output: 40kV/150A(9MW), 40kV/300A(18MW)
- PW: 500ns~10us
- PRR: ~5kHz
- Average Power: 12kW
- Input: 3*380Vac
- Compact, High reliability for Arc
HVP-40100
- Solid state modulator for X-band magnetron, PEF(Pulsed Electric Field)
- Pulse Output: 40kV/100A(4MW)
- PW: 2us~10us
- PRR: ~200Hz
- Average Power: 1kW
- Input: 220Vac
- Filament Power included
- Ultra Compact design(36liter)
- Designed for X-band Magnetron
HVP-55200
- Solid state modulator for S-band, C-band magnetron, PEF(Pulsed Electric Field)
- Pulse Output: 55kV/200A(11MW)
- PW: 2us~10us
- PRR: ~200Hz
- Average Power: 8kW
- Input: 3*380Vac
- Filament Power included
- Compact, High reliability for Arc
- Designed for S-band, C-band Magnetron
HVP-60300
- Solid state modulator for high voltage high current pulsed power
- Pulse Output: 60kV/300A
- PW: 5~50us
- PRR: ~3kHz
- Average Power: 15kW
- Input: 3*380Vac
- High reliability for Arc
